Chemical testing - Srem Technologies

A number of standards, requirements specifications ( NADCAP AS7114 / 1 , ASTM E1417 , AMS 2644 , SNECMA DMC 0010 AITM6 -1001 ) are recommanded  to perform various analyses of penetrants used in immersion , including:

  • A monthly measurement of the moisture content for the pre- emulsified penetrants
  • A quarterly monitoring of the fluorescence
  • A complete annual physico- chemical analysis

SREM Technologies offers to perform these analyses to comply with these standards and requirements by sending us a sample of penetrant ( all references accepted). All these analyses are carried out in our laboratory , ensuring a short time (maximum 5 days upon receipt of sample ) according to the standards required .

SREM Technologies also offers packages for annual pre- emulsified penetrant and post-emulsion penetrant , which will allow you for 1 year to meet the particular requirements of the following specifications and requirements : NADCAP AS71114 / 1 - ASTM E 1417 - AITM 6-1001.

Annual Packages NADCAP / ASTM - penetrant pre- émulsified

To comply with the requirements and specifications NADCAP - ASTM and AITM  for 1 : a monthly Measurement of water content – a quaterly Control of Fluorescence Intensity –  a  complete analysis physico-chemical – ASTM E1417 - EN ISO 3452-2 , SAE AMS 2644 - AS7114 / 1 ( NADCAP ) - AITM6-1001.

Annual Packages NADCAP / ASTM - penetrant post émulsion

To comply with the requirements and specifications NADCAP - ASTM and AITM  for 1 year, including : a quaterly Control of Fluorescence Intensity – a complete annual analysis physico-chemical, such as : ASTM E1417 - EN ISO 3452 -2 - SAE AMS 2644 - AS7114 / 1 ( NADCAP ) - AITM6-1001.

Physico- chemical analysis of a penetrant, including :

  • Appearance & Color
  • Contamination
  • Moisture
  • Fluorescence Intensity
  • Density
  • Viscosity Test
  • washability
  • Sensitivity Test
  • Water tolerance

Other analyses are also available but are not included in the package NADCAP.

Packaging

We provide you under the NADCAP PACKAGES, all packaging (bottles) in order to send us samples of your pénétrant. The packaging is adapted with no risk of leakage during transport. Volume is also suitable for the analysis to be carried out.

Corrosion Test

Penetrant and emulsion control on monthly or annual period for penetrant and emulsifying, (referring to customer request)
reference : SNECMA DMC 0010 - EN ISO 3452-2 - SAE AMS 2644 - IGC 04.25.100

Thermal Stability of Fluorescence

Annual Inspection of Penetrant, reference : SAE AMS 2644 - EN ISO 3452-2 -

UV stability of Fluorescence

Annual Inspection of Penetrant, reference : SAE AMS 2644 - EN ISO 3452-2 -

Content of Chlorine and Sulfur  & Content of Halogen

Annual control of content, under reference : EN ISO 3452-2 - IGC 04.25.100

Content of Impurities - Fluor - Sulphur – Chlorine.

Annual Control, under reference : SNECMA DMC 0010

A reference Curve for Refractometer can be determined

Oil analysis for MT
Checking conformity under reference AMS 2641 Type 1
